Material : Alloy Steel
| Size | Iain technical parameters | Weight | ||||||
| (m) | F | C | A | B | L | D | E | (kg/100pcs) |
| (mm) | (mm) | (mm) | (mm) | (mm) | （mm） | (mm) | ||
| 8 | 8.6 | 14.0 | 20.0 | 40.0 | 56.0 | 5.0 | 20.0 | 8.0 |
| 10 | 10.8 | 17.0 | 25.0 | 50.0 | 70.0 | 5.0 | 20.0 | 17.0 |
| 12 | 12.9 | 21.0 | 30.0 | 60.0 | 84.0 | 5.0 | 20.0 | 32.0 |
| 14 | 15.1 | 24.0 | 35.0 | 70.0 | 98.0 | 5.0 | 20.0 | 50.0 |
| 16 | 17.2 | 28.0 | 40.0 | 80.0 | 112.0 | 5.0 | 20.0 | 78.0 |
| 18 | 19.4 | 31.0 | 45.0 | 90.0 | 126.0 | 5.0 | 20.0 | 114.0 |
| 20 | 21.5 | 35.0 | 50.0 | 100.0 | 140.0 | 10.0 | 30.0 | 141.0 |
| 22 | 23.7 | 38.0 | 55.0 | 110.0 | 154.0 | 10.0 | 30.0 | 196.0 |
| 24 | 25.8 | 42.0 | 60.0 | 120.0 | 168.0 | 10.0 | 30.0 | 241.0 |
| 26 | 28.0 | 45.0 | 65.0 | 130.0 | 182.0 | 10.0 | 30.0 | 346.0 |
| 28 | 30.1 | 49.0 | 70.0 | 140.0 | 196.0 | 10.0 | 30.0 | 430.0 |
| 32 | 34.4 | 56.0 | 80.0 | 160.0 | 224.0 | 10.0 | 30.0 | 646.0 |
| 36 | 38.7 | 63.0 | 90.0 | 180.0 | 252.0 | 10.0 | 30.0 | 977.0 |
| 40 | 43.0 | 70.0 | 100.0 | 200.0 | 280.0 | 10.0 | 30.0 | 1294.0 |
| 44 | 47.3 | 77.0 | 110.0 | 220.0 | 308.0 | 15.0 | 45.0 | 1702.0 |
| 48 | 51.6 | 84.0 | 120.0 | 240.0 | 336.0 | 15.0 | 45.0 | 2275.0 |
| 52 | 55.9 | 91.0 | 130.0 | 260.0 | 364.0 | 15.0 | 45.0 | 2841.0 |
| 56 | 60.2 | 98.0 | 140.0 | 280.0 | 392.0 | 15.0 | 45.0 | 3556.0 |
