The following types are available
Jaw both Ends
Eye both ends
Jaw-Eye
Optionals,locknuts
Finish:selfecoloured orgalvanized
| SWL | A | B | C | D | E | WEIGHT | |||||
| DIA | LENGTH | DIA | JAW | OVAL EYE | Per | ||||||
| SCREW | OF | OF | DIA | DIA | INSIDE | DIA | INSIDE | piece | |||
| BODY | BODY | PIN | LENGTH | HIDTH | LENGTH | HIDTH | |||||
| D1 | D2 | D3 | D4 | E1 | E2 | E3 | |||||
| m.Tons | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | kg |
| 0.10 | 6 | 102 | 12 | 3 | 5 | 15 | 7 | 6 | 15 | 8 | 0.11 |
| 0.15 | 88 | 110 | 15 | 4 | 6 | 16 | 9 | 7 | 19 | 10 | 0.23 |
| 0.375 | 10 | 152 | 21 | 5 | 8 | 21 | 11 | 8 | 25 | 11 | 0.28 |
| 0.50 | 12 | 175 | 27 | 6 | 10 | 25 | 13 | 11 | 30 | 14 | 0.8 |
| 0.75 | 16 | 229 | 27 | 10 | 12 | 40 | 18 | 14 | 41 | 16 | 1.4 |
| 1.125 | 20 | 229 | 33 | 12 | 16 | 45 | 20 | 16 | 51 | 22 | 2 |
| 1.60 | 22 | 305 | 33 | 15 | 18 | 48 | 24 | 16 | 51 | 22 | 3.5 |
| 2.00 | 24 | 325 | 42 | 16 | 22 | 65 | 28 | 19 | 57 | 25 | 4 |
| 2.75 | 28 | 356 | 48 | 18 | 22 | 59 | 30 | 19 | 57 | 28 | 4.5 |
| 3.75 | 33 | 381 | 48 | 20 | 27 | 62 | 34 | 22 | 65 | 35 | 6.5 |
| 4.25 | 35 | 381 | 60 | 22 | 28 | 68 | 38 | 22 | 65 | 36 | 8 |
| 5.00 | 39 | 406 | 60 | 24 | 33 | 74 | 42 | 25 | 74 | 38 | 11 |
The following types are available Jaw both Ends
Eye both ends Jaw-Eye
Optionals,locknuts Finish:selfecoloured orgalvanized
